Feedback Stepper Motor FB28、FB42


✦Micro-step feedback.

✦High loading with point positioning on single axis.

✦High positioning accuracy under 0.2mm between points.

✦Available to be used for image depth control application.
Specifications
Voltage V 4.5~5.5
Current mA 100(Max)
Signal /  A+, A-, B+, B-, Z+, Z-
Frequency Hz 300K
Output Voltage High V 2.4(min)
Low V 0.4(max)
Max. Output Current mA 20
Max. Allowable Rpm rpm 600
Operation/Storage Temperature °C -20~+80
Operation RH85%max
Humidity non-collecting

更新日期(Update):2018.01.29
